HF direct T5 LED tube

T5 LED, T5 Dimmable

HF direct T5 LED tube

Product Model: ECGsmart T5 HE 1449 LED tube

Compatible with most of Electronic Control Gear (ECG) ballast. Directly replace traditional T5 35W fluorescent tube. No ballast bypassing. No fixture rewiring. Help users save more on energy, time and cost with ease. Greatly shorten the payback time and effectively reduce total cost of...
Add Inquiry
Features

Compatible with most of Electronic Control Gear (ECG) ballast. Directly replace traditional T5 35W fluorescent tube. No ballast bypassing. No fixture rewiring. Help users save more on energy, time and cost with ease. Greatly shorten the payback time and effectively reduce total cost of ownership.

(Model: ECGsmart T5 HE 5F LED tube)
Directly retrofit old 1449mm T5 HE 35W fluorescent tube
Function with ECG electronic ballast in existing luminaire.
Work with dimming CC LED driver, such as DALI, 0/1-10V, TRIAC
SDCM ≤ 5 for good discoloration of light over life of tube
15,000 switching cycles
50,000 hour life time
Color rendering index Ra ≥ 82
No bending with high quality aluminum housing.
No mercury or hazardous materials
Note 1: Not applicable to line voltage input (85V~265V).
Note 2: Only suitable for working with electronic ballasts, constant current LED driver.

Our focus is on LED lighting, we provide the solutions that meet the demands of all our customers. Our products are designed to save energy, improve the quality of light This electronic ballast (ECG) compatible LED retrofit tube can bring ease and simplicity to your lighting project. Just directly replace fluorescent lamp (FL) with plug and play installation as well as reuse your luminaire to save the planet by reducing electronic waste. Hugely Lower recycling fee and installation labor cost. The installation of LED lamps is safer, simpler and easier than you expected.

The ECGsmart series T5 LED tubes have complete set of solutions, which include different tube length and wattage, such as 136mm, 212mm, 288mm, 517mm, 549mm, 849mm, 1149mm and 1449mm. Always more than welcome to visit our website or contact with our lighting specialist to know more about our electronic ballast compatible LED solutions.

Specifications
Descriptions Value
Compatibility Electronic ballast or LED driver
Direct Replacement Target Old T5 HE 35W Fluorescent tube
Ballast Driving Voltage Upon ballast output
CC LED Driver Output Voltage 100V ~ 110V DC
CC LED Driver Output Current 165mA DC
Wattage 21W
Conventional Wattage Equivalent 35W
Base Cap Mini bi pin G5
Life Span (Hours) 50000 hrs
Lumens per Watt 130 lm/W
Lumens 2730 lm
Beam Angle (Degrees) 140
Color Rendering Index (CRI) Ra > 82
Diameter 16mm
Length 1449 mm
Color Temperature (CCT) 2700K ~ 6500K
End cap type Aluminum or plastic
PC cover Clear / Milky
Specifications
Order number Direct Replacement Target
ES-T5HE5F-27K-AL Traditional T5 HE 35W 2700K Fluorescent tube
ES-T5HE5F-30K-AL Traditional T5 HE 35W 3000K Fluorescent tube
ES-T5HE5F-40K-AL Traditional T5 HE 35W 4000K Fluorescent tube
ES-T5HE5F-50K-AL Traditional T5 HE 35W 5000K Fluorescent tube
ES-T5HE5F-60K-AL Traditional T5 HE 35W 6000K Fluorescent tube
ES-T5HE5F-65K-AL Traditional T5 HE 35W 6500K Fluorescent tube
