T5 288mm 5W LED Universal Ballast-Compatible & direct AC Voltage LED Tube
T5 LED, Short T5 LED
T5 288mm 5W LED Universal Ballast-Compatible & direct AC Voltage LED Tube
Product Model: EA T5 HE 288 LED tube
Electronic ballast (ECG) compatible
Magnetic ballast (CCG) compatible
After removing ballast, replaces 8W T5 288mm fluorescent tube, AC: 100-240V.
Add Inquiry
Magnetic ballast (CCG) compatible
After removing ballast, replaces 8W T5 288mm fluorescent tube, AC: 100-240V.
Features
Electronic ballast (ECG) compatible
Magnetic ballast (CCG) compatible
After removing ballast, replaces 8W T5 288mm fluorescent tube, AC: 100-240V.
(Model: EA T5 HE 288 LED tube)
- Directly replaces T5 8W 288mm fluorescent tube
- Compatible for direct installation with ballast or use after ballast removal
- Double-ended power input
- Lifespan up to 30,000 hours
- Ra ≥ 82
- Complies with international standards; the tube contains no heavy metals such as lead or mercury
- Low glare, flicker-free design
- Non-dimmable
Specifications
| Specification | Value |
| Direct Replacement Target | T5 HE 8W fluorescent tube |
| Compatibility | ECG Electronic ballast CCG Magnetic ballast |
| Input Voltage | 100-240VAC |
| Wattage | 5W |
| Replaced fluorescent tube wattage | 8W |
| Base Cap | Mini bi-pin G5 |
| Life Span (Hours) | 30,000 hrs |
| Beam Angle (Degrees) | 300° |
| Lumens | 500 lm |
| PC Cover | Frosted |
| Diameter | 16mm |
| Length | 288mm |
| Color Rendering Index (CRI) Ra | > 82 |
| Color Temperature (CCT) | 2700K ~ 6500K |
| Lumens per Watt | 100 lm/W |
Note: Non-dimmable; can replace traditional T5 fluorescent tubes. For any inquiries, please contact us.
